Product Information

CG-FXII Series

  • Liên hệ để biết giá

World standard of multi cutting plotter


CG-160FXII
  • Continuous crop mark detection
  • Long accurate tracking
  • FineCut – Plug-in for print & cut solutions

Line-up


*Media baskets are optional.


CG-75FXII

CG-75FXII

Effective cutting area 760mm×51m(29.9"×167')




CG-130FXII

CG-130FXII

Effective cutting area 1300mmx51m(51.2"x167')




CG-160FXII

CG-160FXII

Effective cutting area 1600mmx51m(62.9"x167')


CG-FXII Series Spec



  CG-75FXII CG-130FXII CG-160FXII
Acceptable sheet width 90mm~1,040mm (3.54"~40.9") 90mm~1,580mm (3.54"~62.0") 90mm~1,880mm (3.54”~74”)
Acceptable roll sheet Outer less than φ200mm , Roll weight less than 18kg Outer less than φ200mm Roll weight less than 22kg
Effective cutting area*1 760mm x 51m(29.9" x 167') 1,300mm x 51m(51.2" x 167') 1,600mm×51m(62.9”×167’)
Maximum auto cutting width*2 870mm (34.2”) 1,425mm (56.1”) 1,720mm (67.7”)
Maximum cutting speed 100cm/s (39.3"/s)
Maximum moving speed 140cm/s (55"/s)
Adjustable speed range*3 1-10cm/s : 1cm step adjustment
(0.39"-3.94"/s : 0.39" step adjustment)
10-50cm/s : 5cm step adjustment
(3.94"-19.68"/s : 2" step adjustment)
50-100cm/s : 10cm step adjustment
(19.68"-39.37" : 3.94" step adjustment)
Mechanical resolution 5µm(0.0002")
Command resolution 25µm or 10µm(0.001" or 0.0004")-MGL-IIc
Repeatability ±0.2mm (Excluding shrinkage / expansion caused by the film temperature)
Tekanan pen 400g
Range of down pressure Cutter 10~20g(2g step), 20~100g(5g step), 100~400g(10g step)
Pouncing 10~20g(2g step), 20~100g(5g step), 100~400g(10g step)
Pen 10~20g(2g step), 20~100g(5g step), 100~150g(10g step)
Acceptable sheet*4 Vinyl up to 0.25mm(0.01")thickness,
Fluorescent type vinyl Reflective sheet
Acceptable sheet for pouncing*5 Paper thickness: 0.06~0.13mm (0.0024"~0.005")
Applicable tools*6 Cutter, Water based ball-point pen,
Oil based ball-point pen, Pouncing tool
Type of command MGL-IIc
Interface RS-232C,USB
Receiver buffer size 30MB Standard (20MB when in sorting)
Operational Temperature 5~35°C (41~95°F)
Humidity 35~75%(Rh) Non-condensation
Power requirement AC100V~240V
Power consumption 130VA or less
Dimensions (WxDxH) 1,285mm(50.5")x
700mm(27.5")x
1,217mm(47.9")
1,825mm(71.8")x
700mm(27.5")x
1,217mm(47.9")
2,125mm(83.6")x
700mm(27.5")x
1,217mm(47.9")
Weight (with stands) 50kg(110 lbs.) 60kg(132 lbs.) 69kg(152 lbs.)

All trademarks or registered trademarks are the property of the respective owners. Specifications are subject to change without notice.

  • *1: Maximum sheet feeding length differs depending on the software.
  • *2:Sheet width to cut off from the roll.
  • *3:Restricted sheet width.
  • *4:Provided that the blade specific to fluorescent type vinyl (SPB-0007)and the blade specific to reflective sheet (SPB-0006)are used.
  • *5:Pouncing tool intended specifically for pouncing shall be used.
  • *6:The goods on the market are φ8~φ9 Pen. No guaranty with accuracy, and image quality.

High speed continuous crop mark detection


High speed continuous crop mark detection

Light pointer easily adjust the head position to crop marks

An optical sensor enables automatic consecutive detection of crop marks throughout the nested image which the Inkjet printer prints, in combination with the automatic adjustment function to obtain precise contour cutting.


By continuously detecting a maximum of 4 points, nested images in both X axis and Y axis can be cut aligning each image automatically.


Accurate media feeding ensures precise contour cutting over longer-length prints.


Necessary media length is fed in advance to reduce tension during cutting. This functions increases the precision of long-length print media cutting.

“HALF CUT”mechanism, a proprietary technology of Mimaki


CG-FXII Series

With the original half cut function, the backing sheet can be cut leaving a little bit of half cut connecting points,which can be easily detached when necessary.Various media without backing sheets can be also cut.


CG-FXII Series

Engineered Head Unit


CG-FXII Series

Media secara otomatis dipotong dengan pemotong lembaran standar


Other functions


  • Selectable clamp pressure with high and low setting ensures accurate cutting of various media.
  • Selectable three jog speeds ensure proper and easy positioning of the head to the point.
  • Over-cut function makes the starting and ending points overlapped, which eliminates uncut portion of the media.
  • Media can be loaded from back or front.
  • Up to 6 roll media can be set at a time(1 set standard).
  • Plug-in cutting software for CorelDRAW and Illustrator is included.
  • A special adaptor to use commercially available pens and USB interface are included.
